Ortofon SPU Classic N - MC Element
€ 899,00
Prijs incl. BTW (21%) € 156,02
Uitvoering
Geschatte levertijd
1 dag
Op voorraad
1
Productgegevens
Merk: Ortofon
Kwaliteitsklasse: High End
Type element: MC (Moving Coil)
EAN: 5705796240221
De lijn SPU N elementen bieden dezelfde eigenschappen als de SPU tegenhangers, zijn daarentegen uitgevoerd zonder geïntegreerde headshell. Een bijpassende headshelll-adaptor is los verkrijgbaar.
Ortofon SPU Classic N - MC Element
The SPU Classic N provides the same sound reproduction properties as the SPU Classic GM series, but is sold without the integrated headshell unit. The SPU Classic N is a Moving Coil (MC) cartridge with an 18µm spherical stylus profile. Listeners who wish to mount the SPU Classic on a traditional headshell may do so, and those with vintage SPU-type headshells can use the Classic N to recreate an authentic and functional SPU cartridge.
Specifications
- Output voltage at 1000 Hz, 5cm/sec. 200 µV
- Channel balance at 1 kHz < 1 dB
- Channel separation at 1 kHz > 20 dB
- Channel separation at 15 kHz > 10 dB
- Frequency range at - 3dB 20-25.000 Hz
- Frequency response 20-20.000 Hz ± 3 dB
- Tracking ability at 315Hz at recommended tracking force *) 65 µm
- Compliance, dynamic, lateral 8 µm/mN
- Stylus type Nude spherical
- Stylus tip radius R 18 µm
- Tracking force range 3,0-5,0 g (30-50 mN)
- Tracking force, recommended 4,0 g (40 mN)
- Tracking angle 20°
- Internal impedance, DC resistance 6 Ohm
- Recommended load impedance > 10 Ohm
- Coilwire material High Purity Copper (OFC)
- Cartridge colour Black
- Cartridge weight 13 g
*) Typical value
