FEATURES
Top of the line double-shielded α (Alpha)-OCC conductor interconnects, power cords and digital cables featuring extraordinary build quality and Formula GC-303 antimagnetic EMI-absorbent modules Surrounding the cable offering greater resolution, more powerful dynamics, and virtuoso performances from all your components. All connectors are rhodium-plated for optimal signal transfer.
•Double-shielded Alpha-OCC Conductors eliminate radiated noise
•Formula GC-303 Antimagnetic EMI-Absorbent Modules surround each cable
•High performance beautifully engineered XLR connectors [FP-601M (R)] and [FP-602F (R)]
transfer signal without reflections for extremely low jitter performance
•Pins high-contact luxuriously-finished nonmagnetic rhodium-plated phosphor bronze for stable
Furutech Pure Transmission signal
•Additionally shielded with special fiberglass and 0.12 mm Alpha conductor braid
•Insulated with air-foamed HDPE reducing capacitance and damping vibration
•Results in greater resolution, clarity, powerful dynamics, and an ultra-quiet soundstage in which
music develops more fully without artificial upper-frequency “presence region” glare.
•GC-303 allows a deeper, tighter bass to form a solid foundation for the rest of the frequency range,
better defining the original recording’s venue. Natural, unforced detail reveals nuance and energy
for an engaging musical experience.
Alpha Conductor Is Composed Of Fine PCOCC Wire Strands Treated With Furutech’s Alpha Cryogenic and Demagnetizing Process
SPECIFICATIONS
Construction and Materials
•30-strand Alpha-OCC Conductor ・ 0.18mm , 1.14mm diameter
•Insulation: 30％ air-foamed HDPE (Red/White) 2.60mm diameter
•Cable Lay: Two twisted cores with cotton yarn
•Cable Wrap: Non-woven fabric wrap approx. 5.8mm diameter
•Shield-1: 0.12mm braided Alpha Conductor braid density: 80％ UP x 6.3mm diameter
•Sheath: Two layers flexible PVC (Dark Brown) 8.0mm diameter
•Shield-2: Special fiberglass and copper wire stranded braid
•Jacket: Nylon yarn braid approx. 10.5mm diameter.
•Shield-3: Special EMI and noise-absorbent Formula GC-303 module
•Connectors: Male [FP-601 M (R)] and female [FP-602 F (R)]
Electrical Properties of Cable Test Method
•Max. Conductor Resistance 26.4 Ω／km JISC3005 6 20℃
•Min. Insulation Resistance 1000 MΩ-km JISC3005 9.1 20℃
•Dielectric Strength AC. 500 V／1 min. JISC3005 8
•Electrostatic Capacitance Approx 42 PF／m at 1 KHz
•Characteristic Impedance Approx 120 Ω at 100 KHz
